| POE交换机型号 | 型号 | 总端口 | POE端口数 | POE标准 | 端口功率 | 总功率 |
| P1005-4POE-65W | 5个10/100M电口 | 4 | IEEE 802.3af/at | 15.4W/30W | 65W | |
| P1008-8POE-150W | 8个10/100M电口 | 8 | IEEE 802.3af/at | 15.4W/30W | 150W | |
| P3008-4POE-65W | 8个10/100/1000M电口 | 4 | IEEE 802.3af/at | 15.4W/30W | 65W | |
| P3008-8POE-150W | 8个10/100/1000M电口 | 8 | IEEE 802.3af/at | 15.4W/30W | 150W | |
| P2018M-16POE-300W |
14个10/100M电口 2个10/100/1000M电口 2个千兆SFP光口 |
16 | IEEE 802.3af/at | 15.4W/30W | 300W | |
| P2026M-24POE-450W |
20个10/100M电口 4个10/100/1000M电口 2个千兆SFP光口 |
24 | IEEE 802.3af/at | 15.4W/30W | 450W | |
| P3008M-4POE-65W | 8个10/100/1000M电口 | 4 | IEEE 802.3af/at | 15.4W/30W | 65W | |
| P3008M-8POE-150W | 8个10/100/1000M电口 | 8 | IEEE 802.3af/at | 15.4W/30W | 150W | |
| P3018M-16POE-300W |
16个10/100/1000M电口 2个千兆SFP光口 |
16 | IEEE 802.3af/at | 15.4W/30W | 300W | |
| P3026M-24POE-450W |
24个10/100/1000M电口 2个千兆SFP光口 |
24 | IEEE 802.3af/at | 15.4W/30W | 450W | |
| POE供电器型号 | PSE501-15W | 2个10/100M电口 | 1 | IEEE 802.3af | 15.4W | 15.4W |
| PSE501G-15W | 2个10/100/1000M电口 | 1 | IEEE 802.3af | 15.4W | 15.4W | |
| PSE501-30W | 2个10/100M电口 | 1 | IEEE 802.3af/at | 30W | 30W | |
| PSE501G-30W | 2个10/100/1000M电口 | 1 | IEEE 802.3af/at | 30W | 30W | |
| POE分离器型号 | PD501-12V-15W | 2个10/100M电口 | 1 | IEEE 802.3af | 15.4W | 15.4W |
| PD501G-12V-15W | 2个10/100/1000M电口 | 1 | IEEE 802.3af | 15.4W | 15.4W | |
| PD501G-12V-30W | 2个10/100/1000M电口 | 1 | IEEE 802.3af/at | 30W | 30W |
